Key Specs: Production Rate 55 loads per hour Machine Dimensions 119.5 ” L x 66 ” W x 86.5 ” H Maximum Load Size 50 ” L x 50 ” W x 80 ” H Load Weight 5000 lbs Approximate Shipping Weight 2800 lbs Electrical Requirements 120 V / 1 ph / 60 Hz 15 A Controls Allen Bradley MicroLogix 1200 PLC 24V control system Current overload protection NEMA 4/12 control cabinet Autoheight sensing photoeye Power on/off switch and status light Start/stop push button Large emergency stop (push / pull type) Manual carriage up/down function Variable table speed (16 RPM) with automatic home position Separate up/down carriage speeds adjustment Separate top and bottom wrap selectors (0-9) Reinforced wrap/manual rotation control Film tension adjustment Top cover pause switch (Splash proof program) Mode switch (Manual or Automatic) Pull cord with 40′ of cable (to be installed by customer) Separate station on front of tower with clamp jog, an additional E-stop Lack of film alarm Structure 14 gauge formed steel tower Forklift Portable base design (from back only) Heavy duty structural steel construction Film Delivery System 20″ NO-THREAD® Powered Pre-Stretch Carriage 1 HP AC motor with Allen Bradley variable frequency drive Lifetime warranty on pre-stretch rollers blue compound Film force release for easy pull at start and end of cycle 50-400% pre-stretch ratio (preset to customer spec, Std 200%) Electronic film tension control with analog sensor Film roping bar Lexan roller cover for operator safety Proximity sensor on carriage gate to ensure gate is properly closed Film Tail Treatment Automated Cut/Clamp & Wipe system Pulse controlled cutter Film alignment arm & Brush on film tail treatment Film Carriage Drive 1 HP AC motor with Allen Bradley variable frequency drive Two #50 carriage lifting chains enclosed in tower for safety Bearing supported maintenance free guide wheels Turntable 65″ dia. 3/8″ steel plate 32 heavy duty non metallic lube-free table supports 3-1/8″ table height 2-3/8″ high base with full surround for safety and strength Ramp accessible on all three sides Turntable Drive 0-16 RPM variable speed 1 HP AC motor with Allen Bradley variable frequency drive #50 ANSI heavy duty chain drive Electronic soft start/stop Positive turntable alignment controlled by proximity sensor Technical Information The machine is provided with a manual including electro/mechanical schematics and drawings, troubleshooting guide & Installation instructions
