Key Specs: Production Rate 55 loads per hour Machine Dimensions 111.5 ” L x 51 ” W x 99 ” H Load Weight 8000 lbs Approximate Shipping Weight 2500 lbs Electrical Requirements 120 V / 1 ph / 60 Hz 15 A Controls Allen Bradley MicroLogix 1000 or 1200 PLC 24V control system Current overload protection NEMA 4/12 control cabinet Autoheight sensing photoeye Power light indicator (Basic)* Power On/Off switch and status light (Standard)* Start/stop push button Large emergency stop (push / pull type) Manual carriage up/down function Variable table speed (16 RPM) with automatic home position Carriage speed adjustment Top and bottom wrap selectors Reinforced wrap/manual rotation control Film tension adjustment Lack of film alarm Structure 14 gauge formed steel tower Forklift Portable base design from both ends Heavy duty structural steel construction Film Delivery System 20″ NO-THREAD® Powered Pre-Stretch Carriage 1 HP AC motor with Allen Bradley variable frequency drive Lifetime warranty on pre-stretch rollers blue compound Film force release for easy pull at start and end of cycle 50-400% pre-stretch ratio (preset to customer spec, Std 200%) Electronic film tension control with analog sensor Film roping bar Lexan roller cover for operator safety Proximity sensor on carriage gate to ensure gate is properly closed Film Carriage Drive 1 HP AC motor with Allen Bradley variable frequency drive Two #50 carriage lifting chains enclosed in tower for safety Bearing supported maintenance free guide wheels Turntable 51″ x 51″ octagonal table 3/8″ thick 13 3/8″ table height Turntable Drive 1 HP AC motor with Allen Bradley variable frequency drive 0-16 RPM variable speed Direct drive with pinion and ring gear Electronic soft start/stop Positive turntable alignment controlled by proximity sensor Technical Information The machine is provided with a manual including electro/mechanical schematics and drawings, troubleshooting guide & Installation instructions
